The Wallenstein WX470 is a 20-ton skid steer log splitter with horizontal and vertical splitting positions for handling both routine firewood and large, heavy rounds. Its vertical position lets you work with oversized logs closer to ground level, reducing the need to lift them onto the splitter bed.
With a 24″ split opening, 4″ cylinder, 9″ wedge, and universal quick attach, the WX470 is built for efficient firewood processing with compatible skid steers and compact track loaders. Hydraulic hoses and couplers are included for a straightforward connection to the carrier machine.
What is the advantage of the WX470’s horizontal and vertical design?
Horizontal operation works well for routine firewood processing, while the vertical position lets you split large, heavy rounds without lifting them onto the splitter bed.
How much splitting force does the WX470 provide?
The WX470 provides 20 tons of splitting force.
What is the maximum log length?
The WX470 has a 24″ split opening.
How much hydraulic flow does the WX470 need?
The recommended hydraulic flow is 10 GPM.
How fast does the WX470 cycle?
Average cycle time is 6.62 seconds, with a 13.24-second full cycle. Actual cycle speed depends on hydraulic flow from the carrier machine.
Does the WX470 fit skid steers and compact track loaders?
Yes. It uses Universal Quick Attach for compatible full-size skid steers and compact track loaders.
Are hydraulic hoses and couplers included?
Yes. Hydraulic hoses and couplers are included.
Can I add a 4-way wedge?
Yes. The WX470 accepts the optional W4120 4-Way Wedge.
What other accessories are available?
The WX470 is also compatible with the W4211 Clamp On Shelf and W4213 Stroke Limiter.
What colors are available?
Black, Blue, Orange, Red, Yellow, Grey, Green, and Realtree APX Camo are available.
Note: The WX470 uses Universal Quick Attach and is recommended for approximately 10 GPM hydraulic flow. Verify mounting interface, auxiliary hydraulic flow and pressure, couplers, operating capacity, and machine configuration before ordering.
Common Compatible Machines
Bobcat: S450, S510, S530, S550, S570, S590, S62, S64, S64-2, S66, S66-2, S76, S76-2, S86, S86-2, T450, T550, T590, T595, T62, T64, T64-2, T66, T66-2, T76, T76-2, T86, T86-2, T650, T740, T770
Caterpillar: 226D3, 232D3, 236D3, 242D3, 246D3, 262D3, 272D3, 239D3, 249D3, 259D3, 279D3, 289D3, 299D3, 250, 255, 260, 265, 270, 275, 285
John Deere: 316GR, 318G, 320G, 324G, 330G, 332G, 317G, 325G, 331G, 333G
Kubota: SSV65, SSV75, SVL65-2, SVL65-2s, SVL75-3, SVL97-2, SVL97-3, SVL110-3
CASE: SR160B, SR175B, SR210B, SR240B, SR270B, SV185B, SV280B, SV340B, TR270B, TR310B, TR340B, TV370B, TV450B, TV620B
New Holland: L316, L318, L320, L321, L328, L334, C327, C330, C332, C334, C337, C345, C362
JCB: 215, 225, 270, 300, 215T, 250T, 270T, 300T, 400T, 2TS-7T, 3TS-8T, 3TS-8W, 4TS-8T
Takeuchi: TL6R, TL8R-2, TL10V-2, TL11R3, TL12R-2, TL12V-2
ASV: RT-40, RT-50, RT-65-1C, VT-75-1C, VT-80-1C, VT-100, RT-135, RS-75, VS-75
Wacker Neuson: ST27, ST31, ST37, ST45, ST50
Wallenstein provides a 5-year limited warranty for consumer use and a 2-year limited warranty for commercial use, subject to its warranty terms and exclusions.
Horizontal or Vertical Operation
The WX470 gives you the flexibility to process ordinary firewood horizontally or move into the vertical position when a round is too large or heavy to comfortably lift.
Less Manual Lifting
Vertical splitting keeps large rounds closer to ground level, allowing the machine to handle more of the work during firewood processing.
Uses Carrier Hydraulics
The WX470 runs from the skid steer or compact track loader’s auxiliary hydraulic system, eliminating the separate engine and fuel system used by self-contained splitters.
Built for Everyday Firewood Processing
A 24″ opening, 20 tons of splitting force, and a relatively quick hydraulic cycle make the WX470 a practical setup for regular firewood work.
