The Stinger Manure Tine Attachment is built for farms, feedlots, and livestock operations that need to move loose and packed material fast. Designed with long heavy-duty bottom tines instead of a solid bucket floor, it slides under manure, bedding, silage, and feed waste while letting excess debris fall through.

This open tine design reduces unnecessary weight, improves cleanup speed, and handles the daily jobs that need done whether conditions are wet, packed, or messy. If you run cattle, dairy, horse, or mixed livestock operations, this is the kind of attachment that pays for itself quickly.

Features

• 40 inch long heavy-duty tines slide under packed manure, bedding, and silage easier than a solid bucket edge
• 45 degree angled tine tips improve penetration into matted or compacted material
• 8 inch tine spacing with approx. 6 inch openings helps separate loose debris while carrying usable material
• 2 inch cold rolled steel shafts provide strength for repeated daily use
• Replaceable bolt-in tines reduce long-term ownership cost if damage occurs
• Heavy-duty 4 x 4 structural tubing frame built for agricultural workloads
• Optional open back or solid back design lets you choose capacity vs visibility

Saves Time

Clean pens, move bedding, and load manure faster with fewer passes

Carries What You Need

Open tine layout drops excess debris and liquid instead of hauling dead weight

Cuts Daily Labor

One operator can handle cleanup and material movement quickly

Built for Farm Use

Designed for manure, bedding, silage, compost, and livestock chores

• Cleaning cattle lots and pens
• Handling manure and compost
• Moving straw and bedding
• Loading silage and feed waste
• Barn cleanup
• Daily livestock chores

• Width Options: 60", 68", 76", 84"
• Tine Length: 40"
• Tine Tip Angle: 45 degrees
• Tine Spacing: 8" on center
• Approx Openings: 6"
• Tine Shaft Material: 2" cold rolled steel
• Frame: 4" x 4" structural tubing
• Back Angle: 75 degrees
• Back Options: Open back or solid back
• Mount: Universal skid steer quick attach
• Function: Scooping, lifting, separating, transporting loose material

Common Compatible Skid Steers

Bobcat- S150, S160, S175, S185, S205, S450, S510, S550, S570, S590, S630, S650, S66, S76, T450, T550, T590, T650, T66

Caterpillar- 216B, 226B, 236B, 242D, 246D, 259D, 262D, 272D

John Deere- 312GR, 314G, 316GR, 317G, 318G, 320G, 324G, 325G

Kubota- SSV65, SSV75, SVL65-2, SVL75-2, SVL97-2

Case- SR130, SR150, SR160, SR175, SR200, SR210, SV250, SV280

New Holland- L213, L215, L218, L220, L223, L225, L228, C232, C238

Is this a bucket or forks?

It functions more like a manure fork with a framed back support. It uses bottom tines instead of a solid bucket floor.

Why is open tine design better?

It allows liquid, mud, and loose debris to fall through so you move useful material instead of dead weight.

Can this handle packed manure or bedding?

Yes. The long tines with angled tips are designed to get under compacted material.

Are the tines replaceable?

Yes. Individual bolt-in tines can be replaced if damaged.

Can I use it for silage or feed waste?

Yes. It works very well for loose agricultural materials beyond manure.

What size should I choose?

Choose based on machine lift capacity and workload. Larger machines typically benefit from wider models.

What is the biggest mistake people make buying one?

Buying a solid bucket when an open tine design would work faster and carry less waste.

Stinger Attachments products are backed by a 2-year manufacturer warranty covering defects in materials and workmanship for the original purchaser. Twice the length of industry standard.

• Structural components and welds are covered under normal use
• Wear items such as cutting edges and skid shoes are considered maintenance
• Warranty applies to properly operated equipment within rated use

This warranty does not cover damage caused by misuse, improper operation, or normal wear and tear.

All warranty claims are handled through Echo Equipment, where you’ll work directly with our team to get issues resolved quickly without the runaround.
