Product Overview
Description
The Stinger Series 2 Material Bucket (MB2) is built to move more material in less time. Designed with a deep profile and optimized rollback angle, this bucket is made for operators who care about efficiency, not just digging.
Whether you are loading snow, mulch, grain, or loose material, the MB2 carries more per pass than a standard bucket. That means fewer trips, faster cycles, and more work done every day. This is not a digging bucket. It is built for volume and productivity.
Features
- Deep profile bucket design around 40 inch depth increases capacity and load efficiency
- High rollback angle around 68 degrees helps keep material contained during transport
- 3/16 inch Grade 50 steel shell balances strength and weight for daily use
- 1/4 inch reinforced side plates add durability where it matters most
- 1/2 inch by 4 inch wear bars on underside extend life in abrasive conditions
- Bolt on or weld on cutting edge options for easy maintenance or permanent durability
- Low profile back around 23 inches improves operator visibility
- Universal skid steer quick attach for fast hookup
Benefits
Saves Time
Move more material per pass and reduce the number of trips
Increases Productivity
High capacity design helps you get through jobs faster
Reduces Fuel and Wear
Fewer cycles mean less machine runtime and lower operating cost
Built for Daily Use
Handles snow, ag work, and material handling without slowing down
Ideal For
- Moving dirt, gravel, and aggregate
- Mulch, topsoil, and landscaping material
- Agricultural use including feed and manure
- Snow removal and bulk material handling
- Construction and property maintenance
Specifications
- Width Options: 60 inch, 66 inch with additional sizes depending on build
- Bucket Depth: around 40 inches
- Back Height: around 23 inches
- Rollback Angle: around 68 degrees
- Shell Material: 3/16 inch Grade 50 steel
- Side Plates: 1/4 inch steel
- Wear Bars: 1/2 inch by 4 inch steel underside
- Cutting Edge Options: bolt on reversible or weld on
- Mount: skid steer quick attach
- Construction: reinforced steel frame
- Function: material handling and bulk transport
Compatible Machines
Recommended Machine Specs
- Lift Capacity: 1500 to 3500 pounds or more
- Machine Type: skid steer or compact track loader
Common Skid Steers:
Bobcat- S150, S160, S175, S185, S205, S450, S510, S550, S570, S590, S630, S650, S66, S76, S86, T140, T180, T190, T450, T550, T590, T630, T650, T66, T76, T86
Caterpillar- 216B, 226B, 236B, 246B, 252B, 262B, 272B, 242D, 246D, 259D, 262D, 272D, 279D, 289D, 299D
John Deere- 240, 250, 260, 270, 280, 312GR, 314G, 316GR, 317G, 318G, 320G, 323E, 324G, 325G, 326E, 328E, 329E, 331G, 332G, 333G
Kubota- SSV65, SSV75, SVL65, SVL65-2, SVL75, SVL75-2, SVL90, SVL95, SVL97-2
Case- SR130, SR150, SR160, SR175, SR200, SR210, SR220, SR240, SV185, SV250, SV280, SV300, SV340
New Holland- L213, L215, L218, L220, L223, L225, L228, L230, L234, C227, C232, C238, C245, C332, C337
Takeuchi- TL6, TL8, TL10, TL12
ASV- RT25, RT30, RT40, RT50, RT60, RT65, RT75, RT120
FAQs
What makes this different from a standard dirt bucket
This bucket is designed for capacity, not digging. The deeper profile allows you to carry more material per load.
What materials is this best suited for
Light to medium density materials like snow, mulch, grain, feed, and loose dirt where volume matters most.
Can I use this for digging
Light digging is fine, but it is not built for aggressive excavation or hard ground.
Why is rollback angle important
A higher rollback angle helps keep material in the bucket during transport, especially with loose or flowing material.
What is the benefit of the deeper bucket design
You can carry more per pass which reduces cycle time and increases productivity.
Should I choose bolt on or weld on cutting edge
Bolt on edges are easier to replace. Weld on edges are more permanent and suited for heavier use.
What size should I choose
Match the width to your machine and the material you are moving. Wider buckets move more but require more lift capacity.
What is the biggest mistake people make with material buckets
Using them like a dirt bucket. This is built for volume, not breakout force.
Manuals/ Warranty
Stinger Attachments products are backed by a 2-year manufacturer warranty covering defects in materials and workmanship for the original purchaser. Twice the length of industry standard.
- Structural components and welds are covered under normal use
- Wear items such as cutting edges and skid shoes are considered maintenance
- Warranty applies to properly operated equipment within rated use
This warranty does not cover damage caused by misuse, improper operation, or normal wear and tear.
All warranty claims are handled through Echo Equipment, where you’ll work directly with our team to get issues resolved quickly without the runaround.
